Double Drum Walk Behind Roller

UNI 40 B Bar Bending Machine

The UNI 40 B is a compact and reliable bar bending machine designed for efficient and precise bending of reinforcement bars in construction and infrastructure projects. Built with a durable copper winding brake motor and robust body structure, it offers consistent performance for small to medium-scale operations.

Key Features:

Bar Bending Capacity: 6 mm to 32 mm diameter rebars
Operation: Fully automatic for ease of use and productivity
Motor Type: Copper winding with brake motor for enhanced safety and durability
Motor Power: 3.7 KW / 4 HP
Phase: Three-phase connection
Motor Speed: 1440 RPM for smooth operation
Voltage: 415V
Production Capacity: Up to 2 Tons per hour
Machine Weight: Approx. 320–330 Kg (based on build)
Dimensions: Approx. 850×800×880 mm

Applications:
Ideal for use in construction sites, civil engineering projects, and precast concrete yards where medium-scale bending is required with speed and accuracy.

Description	Metric	Metric	Metric	Metric	Metric	Metric	Metric	Metric
MODEL	GW42	GW 42 SP	GW 50	GW 52	UNI 42 B	UNI 42 P	uni 50 b	UNI 52 P
Operation	Automatic	Automatic	Automatic	Automatic	Automatic	Automatic	Automatic	Automatic
Bar Bending Diameter	6-32MM	6-25MM	6-42MM	6-42MM	6-32MM	6-32MM	6-42MM	6-42MM
Type of Motor	Copper Winding (Brake motor)	Copper Winding (Brake motor)	Copper Winding	Copper Winding (Brake motor)	Copper Winding (Brake motor)	Copper Winding (Planetary Gear)	Copper Winding	Copper Winding (Planetary Gear)
Motor Power	3.7 KW / 4 HP	3.7 KW / 4 HP	4 KW / 5 HP	4 KW / 5 HP	4 KW / 5 HP	4 KW / 5 HP	4.5 KW/6 HP	4 KW / 5 HP
Phase	Three	Single	Three	Three	Three	Three	Three	Three
Motor Rotation Speed	1440 R/min	1440 R/min	1440 R/min	1440 R/min	1440 R/min	1440 R/min	1440 R/min	1440 R/min
Weight	330KG	330KG	400Kg	470Kg	440Kg.	400Kg	490Kg.	470Kg
Dimension	850800880 mm	850800880 mm	940780860 mm	940780860 mm	850800880 mm	850800880 mm	740940730 mm	940780860 mm
Voltage	415V	220V	415V	415V	415V	415V	415V	415V
Production capacity	2Ton P/h	2Ton P/h	2Ton P/h	2Ton P/h	2Ton P/h	2Ton P/h	2Ton P/h	2Ton P/h
